High availability design


If you have ever travelled in an Indian Railways you would have noticed that the capacity for which the train is supposed is handle holds no meaning because the number of people it will be carrying is just going to be way over. That’s how the passenger load and platforms all across the country are managed. The method mostly works fine, but from time to time there are breakdown and trains are delayed, sometime cancelled but the life goes on as people expect that this will happen with Indian Railways.

When we design and write those big platforms/software something similar happens but the biggest difference is that customers/clients who have paid for the software don’t like those downtimes (cancellations) and slowness (delays). Last 2 years or so I have had so many conversations where 2 key NFRs intersect – Performance and Availability. I have noticed and started to realize that while these two end up being joint at the hip and need to work closely together they still mean a world of difference and what it means when we speak about performance and availability and each of these need to be addressed differently.

Of course, eventually with all many fixes you will eradicate a lot of cases that led to failures but it would have taken you so long and the reputation that the brand holds do dear is already damaged.



The Start

Most project (almost all) in today’s world have some Non Functional Requirements and the 3 that take the top most priority are Performance, Availability and Security. Some numbers that get most often thrown around are:

  • Pages should open in under 1 second and so forth
  • There should be an uptime of 99.99% – which is actually 1.01 minutes per week

And that’s about it. Of course there are more, but 95% of the conversations revolve around the two here. then we go about designing solutions to meet those numbers.



Just before GO Live

Things are al good when we are under implementation and we do everything to make sure we meet those 2 or so numbers met with out design. We do performance modeling and then we execute those performance models and prove out that the trafic model/simulation as to what we understand as client use cases work fine. So that is not we say with confidence that our system will meet the performance needs. In this model, we do take a capacity increase of 40% or so; again based on anayltic and some future growth and we incubate those numbers into our calculations and then we are even sure that our system will be able to handle a bit more if that happens at times.

Now that we are so sure that performance is all good for the traffic we expect to get we believe that our software should continue to work fine because everything will work in the same constraints in which we have tested it. And because those constraints are well defined there should really be no problem with us meeting our availability numbers.



We are in flight Houston

Then the next cool thing happens – we go live and our system that we have build with so much pride and caution and we have tested so much is Live and so many people start to use it. It certainly is an exhilarating feeling seeing your sweat and hard work go live and people are seeing and interacting with what you have build.

Until a time comes when the system goes down. You would be sleeping in middle of the night and you will get a call and someone will be telling you to get up, switch on your laptop and get ready to debug as to why the system went down and get it up and running quick. It takes you a while to think – what the hell just happened. We did everything we had to do. There were even reviews that we did and everything was looking good. How can it go down.

Well there is something called Universe that has a different set of plans for you and those plans just went into motion.

So what happens?

Indian Railways happens :) You realize that there is a traffic pattern that has suddenly come and hit your servers which you did not know. A Chinese search engine has started to crawl all over your site and the site is not even in china. Well it’s a free ride this internet and anyone can get on. Why can some people sitting in a country not see a website that is not supposed to be targeted at them – but we did not have those specifications. We put in all checks but we never anticipated for all those search engines and bots and the crawling they will do.

What do we do?

We fix the problem and put in either a block to stop that traffic pattern or we throttle it or we add servers to handle it. And then we go about thinking okay now i am good; this is done and dusted and wont happen again.

Universe has other plans

Next time someone will add some bad servers into WIP and cluster will fail. and the next time someone will delete the database and it will crash again and the next and the next and the next…

In the whole software development process we miss this key step – to design for this game and how we will be setup to get the system back up and running in that time frame.



Fixing begins

Of course we have to do something but what we do is to start looking at our solution and check why performance is bad. Performance – really? We do everything we can do to fix the performance problem but we spend no time on availability aspect.

Going back to the India Railways analogy I drew upfront; a train – engine and bogeys are built to handle certain load and they was agreed. It cant be more precise as there are seats and there are tickets that need to be bought to get into that train. As long as the number of people that get in there are within those constraints our problems will be much less. Everything around our software (our train) needs to work in tandem. But, it is difficult to control. Internet is much more wider than an Indian Railways and who comes, when they come and how many come is just not predictable. It becomes important to acknowledge that no matter how you do there will always be a model of traffic that will come and visit you that will take your system outside of the known boundaries and more often than not once our system is operating outside of those boundaries it’s bound to fail some point. This is where the Availability and Resilience perspectives need to be brought into the picture.



Next Time do something else too

Availability and Resilience

At their core this perspective asks you to set some designs, practice and most importantly an expectation with your clients as to what you are dealing with. We all know that in the last decade how we run our business and how we deal with internet hosted sites is very different than how we used to make systems in past. I paraphrase from article – “If your site is down, your business will suffer” and yet everyone will want a 24×7 uptime but yet we sold what NFRs – 99.99 (1.06 minutes) or maybe 99.9999 (0.605 seconds) thinking it’s okay. If the expectation is 24×7 why would we even start with something less?

We then need to look at the next 2 most important metrics which we miss all along and we never plan, design or test for. It’s like we take them for granted. It’s the Recovery Time Objective (RTO) and RPO (Recovery Point Objective). As we speak about uptime and outages, whenever we have an unplanned outage and we have promised a certain uptime, we need to have the Operational Ability to be do whatever is needed to get the system up and running. If we designed for 99.99% we need to have methods in place to get system back in 1.06 seconds – it feels like Minute to Win It. In the whole software development process we miss this key step – to design for this game and how we will be setup to get the system back up and running in that time frame.

The Operational ViewPoint

Operation Viewpoint is a key architectural principle that we omit to design for when we are building software systems and platform. How we run software now has been completely changed in the last decade with the cloud hosting. As cloud makes things so easy to provision and host (AWS) we believe that everything should be easy. So where in the past when we used to focus on Availability design a lot more we almost take it for granted. This Viewpoint is something that should become our bread ad butter during the implementation phase with a dedicated team who is going to look at operational processes and tools and provide methods to make the recovery possible in the time it’s expected to be.

Categorize and Prioritize

This is where it becomes critical to have a conversation with out clients and understand how various parts of the systems can be identified and broken down into services. A classification of sorts like “Platinum”, “Gold”, “Bronze” starts to make sense to get the business to prioritize as to what services should get the top most priority incase of an unplanned outage. The focus of the operational design and implementation team then needs to focus on how to look at the system and how to make those services up and running quickly. This is a key inputs for the implementation phase because unless those services are not known there won’t be a way those services are coded such.

Recover and not debug

When these unplanned outages happen, the team which is responsible for managing the system more often than not start with a different mind set. They are like Cops who have reached a crime scene after a crime has happened. They start by looking around for evidence and analyze the crime scene as to what happened. The idea is to look for evidence and then solve the crime and hopefully then find the criminal and put them behind bars. Well we all know it takes so long to get there. With cops, i can see the point – you can’t have cameras in all the home and everywhere, so you will have do post-mortems. But this is a software system and we need to be fire fighters. The idea has to be to put the fire out and do it quickly before it takes the block away. The idea has to be to realize some damage has been done – thats a lost cause; let’s see how we can save what’s left of it.

In softwares that we write and platforms that we host we need to have a something I refer to as “Last know good state” and when an outage happens what we need to do it so just ourselves back to that state. But, when do we do when the state or behavior is not under your control. Going to back to Indian Railways, what do you do when you can’t control the number of people who are coming in on the platform and onto your train – they just keep coming in; no matter if you find a way to replace the train, they will keep coming in. The other way is to of course start adding more trains on the platform. With cloud you can do that and keep adding servers until all the traffic is dealt with. This is where we move seamlessly into Performance and Scalability perspective

This is where we lose sight of the problem and we try to fix something else in modern software.

 So what should do if we can not control traffic. We need an effective mechanism on our train that wont allow everyone to get in. We need to have the ability to know who can get in. We have these ID cards and Turnstil on platform. So if our platforms do not give us those why can we not put those in in our trains. It may not stop all malicious traffic, but it will certainly stop a lot of it. Most importantly you can go back and authorize your Platinum users to get in while you block everyone else.

So in software world, you need to have a cutover switch that will stop all traffic and only allow what is key for business. Unless everything that is coming in is Platinum which is not the case most times, you will be able to recover your most important services easy. Of course there is a degradation of other services but that is something you would already set expectations with your clients and the business. They will be mad but less mad.

The 300

If you have not seen 300, you have got to see this and learn what it can do to your systems and ability to recover if you handle your enemy (the traffic) though a funnel. You will longer and you will get a lot more time to fight the enemy. On top of it, the pressure and stress that the business creates when their platinum services are not available will also be reduced. You can then go about debugging once you have contained.



Nothing is for Free

Of course we do so much more, but the more we do the more it will cost. Back to indian railways, we can either chose to save some money on building my train by not installing those ID cards turnstiles or we can invest that money and ensure we have continuity. The Turnstiles will be more and more complex and will need a lot more fine tuning to handle all scenarios. So if you need to also handle for use cases where you don’t want your turnstile to fail, then you need to install 2 of them on all bogeys which will cost more and the setup goes on.

The point I am trying to make is that when we go from 99% to 99.99% to 99.999% we dont look at the cost drivers and what it will do to the project. We may think – it would mean a few more rounds of performance testing and we should done. We we know now what’s going to happen.

If you fail to articulate to the clients what these numbers will mean to them in terms of cost, you wont ever get them accept the reality of internet and the universe. More often than not you will realize how business will realize that there are services they can live without. Of course, eventually with all many fixes you will eradicate a lot of cases that led to failures but it would have taken you so long and the reputation that the brand holds do dear is already damaged. If you think of this as “risk money” and how you invest in guard your reputation will justify the cost every time – that much i can assure you.

Yahoo Moment: Google gets my content as #1 link on search


I have been blogging off and on in recent times, and last few weeks it has been all about sling, adobe aem (cq), unit testing and what not. As i continue my research and journey to define a developer workflow and unit testing for a AEM Development environment, I found out that Google ranked a piece of my content as #1 when searched for specific key words. The key words are not very common and not a lot of people will see my content as #1, but it’s a mini victory for me to be able to get ranked #1 on a content and not having keywords that has my or my blog name in search terms.



Yahoo Moment

Yahoo Moment

AEM Development Workflow – Part 3 (Coding Old School)


In this series I have been trying to define the various development workflows (that have existed or will arise in near future) and what sort of problems do I see with each of those. We start off by seeing the very first use case that has probably existed for years now “the old school” way of coding in CQ.

Requirements

carousel-authoring-requirements

Image 1: Component Breakdown

It is always beneficial to define what the end result has to be so that we can ensure that we have achieved what we set out to do. I had finally received a HTML for a carousel from my Site Development friend (download here) and our job is to take that carousel and a simple page and make it Content Managed in Adobe AEM. For this purpose I am going to use AEM 6.x as we need to use sightly in later phases. As we you see in the Image 1, you will how the carousel should look like. I have broken the page down to 2 parts/components that we will have to develop:

  1. Carousel Component – this is highlighted in blue block and marked #4
  2. Title Component – For the same of this use case and trying to handle how we can reuse 1 component for various displays, I have classified #1, #2 and #3 into “Text” component

Implementation

CQ Project Structure Setup & Tools

Image 2: Project Structure

Image 2: Project Structure

We are going to use the default CQ structure that allows us to handle components, templates, client libs, etc. I had also setup Eclipse for AEM for development purposed but I was unable to use it to it’s full extend because of the lack of integration and I had to fall back on CRXDE-Lite several times. Following are the details for each of the folders defined:

  • aem6scratchpad: This is the project application folder and is at the root of  everything we would be coding
  • components: this folder holds all the components that we will create in this series
  • components/page: this folder holds the implementation of the templates
  • install: this is the folder where any .jar files will get installed
  • templates: holds the templates which will be used to create pages



Task: Move Static files in AEM

Image 3: Final Output in AEM

Image 3: Final Output in AEM

Image 3, shows us that I was able to achieve what I started to do as the very first step. I set out to take the HTML that I received and just convert the files into a set of files/components in CQ so that while the content would not be managed, but it would look the same. If you go back to where we started this, this Step is going to make or break how the Development Workflow looks like.

Approach: Like a Novice Developer

Coming into this exercise, I did everything that I see happen between a Site Developer and a CQ Developer. I went ahead a bit and did how a CQ developer would work – just dive into the coding and don’t worry about any standards, unit testing (JIT coding as I have come to call it). I have not coded in CQ for a long time from scratch. I have been reviewing code for best practices but a lot of my time last couple of years has been spent into designing solutions. I have looked at code from time to time, but it was a long time since I had coded a set of components and templates from scratch. For this exercise I believe that me in that situation was a very good thing, because that how our developers go though. Some of them are new to this domain, but even when they are well versed with coding, the approach that is taken is more or less what I ended up doing.



Journey: Painful

The journey was nothing but painful all along the way. It took me 5 hours to do what should have been a few minutes job. The Site developer had the code up and running in a HTML file in a browser and all I had to do was to make it work “as is” within CQ. It seemed like the Force of Nature were working against me and everything I did, had a problem in it. I finally got it up and running (the designs done match off as is still), but it was excruciating pain. Here are a list of things that went wrong (and don’t be surprised if you find this the same as it happens at the start of every project):

The set of tools which I thought would do a wonderful job did not cut it out

I was so excited to work with AEM development tools for Eclispe. I got it up and running after a bit of struggle, but working in it only helped in coding a bit. A lot of things that had to be CQ specific like creating components, templates, dialogs weren’t doable in Ecliple. I ad to move into CRXDE-Lite to do all of that. The good part was that I didn’t have to worry about vault (vlt). I could easily synchronize between hosted CQ and Eclipse easy. It made it just a wee-bit easy

I had to write repetitive code into components

Image 4: CQ IncludesRecall those famous set of lines that we need in every component which if don’t get copied something will stop working. If you have forgotten those you can have a look at Image 4 or download this gist. Well, i tried the shortcut – the ultra famous shortcut that Adobe also recommend us to take (they like to call is Adapting it from existing component) which is supposed to be easy.

In the CRXDE Lite, create a new component folder in /apps/<myProject>/components/<myComponent> by copying an existing component, such as the Text component, and renaming it.

Well I did that, but seemed I kept picking up a wrong component because something or the other didn’t happen. There were times, when the template will not come up when I wanted to create the page or once i opened the page, the component did not show up in the side kick. Well, it seemed, one or the other properties were wrong.

Where do the client libs go and where they come from

This is probably was the biggest one. The Site developer has picked up whatever version of client lib he wanted to work with. This was by design – I didnt intentionally tell him what to pick it up. Now when I had to get the JS and CSS into CQ along with the assets I had to ensure what he had picked up worked for me. No surprises there that once i got the carousel in the CQ, the first thing I saw was initialization errors which once solved led into next problem as to not the right JS and CSS were picked up. I finally “as a CQ developer” ended up fixing those and got my Carousel to work just as it was working on HTML. Yes!! all of the interactions were working.



End Result: Not a Production Ready code

I am going to paste snapshots of the files I ended up creating with links to them on GitHub. This code is not final code and does not have 1/10th of the quality standards that I would deliver. But, the code here will clearly highlight how and where the problem starts.

contentpage.jsp

Image 5: Content Page Template Code

carousel.jsp

Image 6: Carousel Code



In Near Future: This is beyond repair

At this point in time, we have seen how the code from Site Developers starts to get into the CQ and what shape it takes. When you take the above and give it to 10 odd developers on a project before you know you will have 10 different standards (or maybe 5) in a project. All of this happens very fast because all one has to do is to drop in a code and make it work. And then we identify the gravity of the problem when we start doing code reviews and realize that this needs more than just refactoring – more often than not this now needs to be fixed only via rewrite. I have not known many projects who have the time and budget to rewrite code. The project releases (thanks to Agile) come to a point when we get workable demos in front of clients – so it all gets tested and done and dusted. With no automated test cases (unit or integration or functional) the risk of breaking something as we make changes it so high that many will just drop and hope that the next component is fixed per a standard.



Fix Something

Absolutely!! Thats the intent. But, do we really need to fix the technology. Do we really see that technology that was at fault here? If we had a different set of technologies would this problem be solved for us? Or can we solve this in another way?



Previous > AEM Development Workflow > The problem statement

Next > AEM Development Workflow > Coding Old School with Standards (TBD)

TIP: Make Sling Testing Framework work


We have been trying to find the right mix of unit testing (Automated) in our project, and I have been looking at various options that Sling has to offer. This was done for development of AEM based projects. I tried to follow a few articles to help me get started and each one of those had some issue or the other. I hope that this article allows you not to spend the 10 hours I did only find out that there are tweaks that are needed to make it work.

  1. http://docs.adobe.com/docs/en/dev-tools/aem-eclipse.html – this is the Adobe’s newly released AEM Dev tools for Eclipse. The documentation targets starting new projects and there is also a documentation to move existing projects into Eclipse, but the documentation is pretty weak while it has depth. When I create a new project using Archetype version 7 and run the tests either via maven or Eclipse 2 errors come up
    1. Dependency for slf4j is missing so test dont run
    2. Once you add that dependency, the tests just dont run. I have tried running via Eclipse JUnit plugin and maven test command. I added an assert statement to fail and test cases do not fail
    3. Still Open – I dont know what is wrong here and why these do not work. Still trying to unravel this mystery
  2. http://labs.sixdimensions.com/blog/2013-06-05/creating-integration-tests-apache-sling/ – First of all this article works if you do exactly as it states you have to do. However, if you have password set to anything but “admin” this will not work. It fails in the steps where it has to check if thebundleshave been installed or not in the sling runtime (hosted one).
    1. The defect is pretty stupid, which i opened in sling’s bug tracking system
    2. Also, the test cases will not work if you are running the test cases via Eclipse plugin for JUnit; it just doesn’t work



Tips to get going quick

If you are looking to work with server side tests for Sling, I strongly recommend that you start with Dan Klco’s article on Sling’s Integration Tests and use it as is. But, If you want to use a hosted server runtime, then you have to make some changed to POM.XML in the project that you download as follows:

Additional Properties needed hosted server

<p class="p1"><span class="s2"><</span>sling.additional.bundle.2<span class="s2">></span><span class="s1">jstl</span><span class="s2"></</span>sling.additional.bundle.2<span class="s2">></span></p>
<p class="p1"><span class="s2"><</span>launchpad.http.server.url<span class="s2">></span><span class="s1">http://54.179.160.9:4502</span><span class="s2"></</span>launchpad.http.server.url<span class="s2">></span></p>
<p class="p1"><span class="s2"><</span>test.server.username<span class="s2">></span><span class="s1">admin</span><span class="s2"></</span>test.server.username<span class="s2">></span></p>
<p class="p1"><span class="s2"><</span>test.server.password<span class="s2">></span><span class="s1">admin</span><span class="s2"></</span>test.server.password<span class="s2">> <!-- this password has <span class="hiddenGrammarError" pre="has " data-mce-bogus="1">to be</span> admin to work because of the defect (-->https://issues.apache.org/jira/browse/SLING-3873) in sling's framework --></span></p>



The following change to the server ready path is needed if you are using AEM 6.x

</pre>
<p class="p1"><span class="s1"><</span><span class="s2">server.ready.path.1</span><span class="s1">></span>/projects.html:src="/libs/cq/gui/components/common/wcm/clientlibs/wcm.js"<span class="s1"><!--</span--><span class="s2">server.ready.path.1</span><span class="s1">></span></span></p>

<pre>



Closing thoughts

Sling testing framework looks to have potential, but the documentation is so bleak to make adoption so tough. I interact with a lot of CQ (Sling) developers every day and almost each one of them have some issues not to use unit testing – unit testing seems to be so chaotic and non-pleasure that it is like a burden. While developers like to do it, they just feel they are spending so much more time in writing test cases than they are writing code and they do not like it. But, here is just one example that working with CQ/Sling tools for doing unit testing is so primitive and not advertised that it makes things so much more difficult for us. Only if Sling/Adobe would improve this not only they would get adoption, people like me would not have to spend several hours just to get it up and running.





AEM Development Workflow – Part 2 (finding the problem)


While this post will be a self sufficient one, I will recommend that you go back and read up on the context and the background on the AEM Development Workflow to be able to fit this on in the bigger picture.

I was planning to do a grand component to be able to prove my point but it turns our that my HTML and CSS3 skills are not that great and I had to wait up on a Site Developer to be able to provide me with a HTML, CSS, JS for a Carousel – and that can take a while. In the interest of me moving forward, I adapted and now I am going to work with the OOTB List component that AEM offers. Why I picked this component because it a very good use case of what we do in AEM a lot of the time in component development. We build lists of everything, actually from how i see every component can inherit from a list component and render either 1 or more; but more about some other time.

Let’s set the background

Let’s open the OOTB List Component and it looks like having a bunch of files that so several things like render lists in a different way, do pagination, show a feed of list, analytics, has a dialog box and a bunch of other things. To how how the component looks like, i created a new page and then dropped the OOTB List Component. I the configured to pick a list of child pages and show me a list of those. The following Image is shows the authoring dialog as well as the output – ignore the Hello World for now (this is me being lazy). We can clearly see that the OOTB component works well and it does what it’s supposed to do.

spad - adwflow part 2 - list component

List (foundation) component authoring configuration and rendering



List component on Geometrixx

List component on Geometrixx

This is all good, but now the real project requirements come into play and the first thing we will notice that we have to show this same list in a different design; a design that was created by designers. Let’s look at the GeoMetrixx Outdoors and let’s open a Product Listing Page (PLP) where we are sure to find ‘a list component’. The image on the right depicts the component and it’s authoring configuration. You will notice a few key differences in both the consumer facing and authoring requirements:

  1. On the Authoring side the most significant is that now the Author is selecting a “Display As”. This property is used by the component logic to apply different styles. These different styles or views as I call it are how the component can be rendered on a page
  2. On the Consumer Side is going to be look an feel like those boxes around a list element (T-Shirt) in this case, of the price and its Currency, etc.

When I open up the code I see the following resource type definition


sling:resourceType = geometrixx-outdoors/components/nav_products

as we go deeper into the code we find that the code for rendering this View (read design) is actually sitting in a localized component of the Geometrixx Outdoors site.

So now let’s look at the code of this rendition from the list component in foundation as well as in the geometrixx (you can get these from Gist), but the lines I want to highlight are as follows

Code from libs/foundation/list


&amp;lt;li&amp;gt;
 &amp;lt;p&amp;gt;
 &amp;lt;a href=&amp;quot;&amp;lt;%= listItem.getPath() %&amp;gt;.html&amp;quot; title=&amp;quot;&amp;lt;%= StringEscapeUtils.escapeHtml4(listItem.getTitle()) %&amp;gt;&amp;quot;
 onclick=&amp;quot;CQ_Analytics.record({event: 'listItemClicked', values: { listItemPath: '&amp;lt;%= listItem.getPath() %&amp;gt;' }, collect: false, options: { obj: this }, componentPath: '&amp;lt;%=resource.getResourceType()%&amp;gt;'})&amp;quot;&amp;gt;&amp;lt;%= StringEscapeUtils.escapeHtml4(listItem.getTitle()) %&amp;gt;
 &amp;lt;/p&amp;gt;
&amp;lt;/li&amp;gt;

Code from geometrixx-outdoors (list)


&amp;lt;li&amp;gt;
 &amp;lt;p&amp;gt;
 &amp;lt;a href=&amp;quot;&amp;lt;%= listItem.getPath() %&amp;gt;.html&amp;quot; title=&amp;quot;&amp;lt;%= StringEscapeUtils.escapeHtml4(listItem.getTitle()) %&amp;gt;&amp;quot;
 onclick=&amp;quot;CQ_Analytics.record({event: 'listItemClicked', values: { listItemPath: '&amp;lt;%= listItem.getPath() %&amp;gt;' }, collect: false, options: { obj: this }, componentPath: '&amp;lt;%=resource.getResourceType()%&amp;gt;'})&amp;quot;&amp;gt;&amp;lt;%= StringEscapeUtils.escapeHtml4(listItem.getTitle()) %&amp;gt;
 &amp;lt;/p&amp;gt;
&amp;lt;/li&amp;gt;

If you have not already spotted, let me highlight the singular fact that codes in their rendering logic include presentation attributes like width, height (one of them has nothing to it will render like plain old HTML as browser does).

Identification of the problem

My Site Development team delivers to me this great looking markup that works very well in my browsers. I just received my Carousel Code from a Site Developer colleague (Thanks a lot Nitin Suri) and I see this great HTML which works fine (download the whole working copy from my Github). This is the where it all goes haywire. This guy Nitin, does not know CQ while is an awesome Site Developer; one of the best I have worked with. And I am a guy who knows little bit of HTML 5, but very little CSS3. JS i do okay. I now have to take up this great looking markup from these static files and create the following in CQ:

  1. A Component called “Carousel” this does everything that the Site Developers have delivered
    1. Identify the set of authoring components in this component; I see some key content areas in there like Main Heading, Sub Heading, Description and some Slides where I presume authors can include images, Text, Rich Text, Videos, Flash (really Flash!!) – for now I will presume only images
    2. Authors can chose how many slides they want, should there be an auto rotate and what should be the wait interval; what sort of effects does this carousel needs to have
  2. A Template called “Landing Page” where this carousel will rendered among other things that I don’t have yet

I don’t see this as a problem, while this is quoted to be the problem that everyone wants to fix and hence as i read it this classic model of coding in CQ does not work. Remember my post earlier here where I spoke about how even Adobe has come up with sightly as the templating language to fix this inefficiency between this handover.

The problem is how we code this component. Rewind to the way the list component is coded, and we see all of the presentation logic, the business logic – all of it is stuffed into this single JSPs. Well if you are going to stuff shit up while coding, you are going to take time to find the meat from the shit. It’s like mining that takes so long to get to the real stones.

So the question is why do we have to code the way we code in classic methods. Why can we not go back and write good code and make everyone’s lives easier. The AEM workflow problem is not really an inefficiency in the handover of HTMLs to CQ developers but how we should have been writing the code to begin with. We start here by seeing where the problem starts and how the code has been written. Unfortunately, we do see the OOTB Code in AEM as provided by Adobe itself are not coded to solve the problem. When I speak with Adobe they make it clear that these are reference sites and are to used as “Self-learning” but little did they know at the time that people will take this a practice and convert this into a culture.



Previous >

Next > AEM Development Workflow – Part 3 Coding Old School

Tip: Using AEM Developer Tools for Eclipse


If you have been working in AEM for a while now, you are probably aware of the tools we used to have like CRXDE, CRXDE-lite, VLT. With the latest release of AEM 6.x, Adobe has released this Eclipse plugin that can be used moving forward. This page here, provides information as to how you can start off your new project development using these tools. However, if you are working on an existing project on a previous version of AEM (say 5.x), then you need to refer to another set of instruction guide here. This instruction guide talks about a “Getting Started in 5 minutes” as to how to create a new project and then import into Eclipse. If you are already on an existing project you may not need, but if you are a maven buff and want to start off by working with a maven archetype then this guide will fail for a specific step. I realized that this guide is incomplete and some key steps are missing to make this work.

If you are interested in using Eclipse for working on JSPs instead of CRXDE, them the step you will be most interested will be How to work with JSPs. For your JSPs to work you will need to add dependencies for TagLibs to compile and this guide provides a list of dependencies which you need to add. That list is not exhaustive and project the content bundle project will not compile. When working on this guide, you have to use the dependencies from this gist.

This is a key step, and unless you get all those dependencies and if your project is brand new your project will not compile. If you are using an existing project it may just work if you have added those dependencies, but from experience as we dont compile JSPs those dependencies will not kick in. The code still works on CQ server because those dependencies are available at runtime.



AEM Development Workflow – Part 1 (introduction)


If you have followed my blogs recently, you would know that I have debated the Development Workflow for a CMS based application being developed on top of Adobe AEM. If you missed those posts you can read here and here. To summarize and set context

The challenge we have seen is too much time spent to integrate the HTML/JS/CSS being delivered by the Site Developers into the AEM’s components and templates. And the solution that seems to be cropping up is not to fix the process but to pick technologies that change the workflow fundamentally. More specifically, I have seen some suggestions that try to solve many other things and lose sight of this simplest of the problems.

Technology should really be an enabler and in this case if there is a technology that can enable us to do something better and faster why not. I am thinking through is if there is a universal solution to this problem and can we apply this solution pattern or technology to all solutions CMS or not; AEM or Tridion, etc.; or does there needs to be a more scientific way of arriving at the solution.

aem-dev-workflowReferring to a few of the slides from Adobe’s presentation presentation here; I want to highlight two specific slides (merged here into one) where the problem now stands in how the components get build and how much time it takes (the problem itself). If you have read the entire presentation, you would already know that Adobe’s answer to fixing the problem is sightly.

What I want to do here is to compare 3 workflows and see what each one has to offer and what’s the best possible way to remove this inefficiency or improve productivity.

  1. Follow the current set of technologies JSP-Java but change the way of working aka different set of tools, trainings and processes
  2. Use Sightly ~ the new templating language pushed by AEM
  3. Use other templating languages like handlebars or angular which are more platform agnostic and goes beyond just CMS and AEM (old school application development also fits)



There will be a set of posts in coming week as we go through each of those 3 ways of writing the application. For the sake of this exercise, I am going to take on one of the most common components ever used in the CMS world – the carousel. For each of these activities I will elaborate upon the steps which entail to reach from a design to end product aka – final working part for a consumer. The solution will be built in Adobe AEM (not going to touch any other set of CMS tools for now; maybe later). For me to be objectively look at the end results, I will use the following parameters for comparison in the methods:

  1. Level of Effort (LOE) spent by a Site Developer in converting the design into a working front-end code
  2. LOE spent by a AEM developer to take up the front-end code and convert it into a CQ Component
  3. LOE spent in any sort of integrations and bug fixes between the two paradigms



As we progress, I will post sample code, screenshots of what I am trying to do. I will also publish a product (Code, Configuration, Content) that you should be able to run on an instance of AEM if you have access to one handy. I will also publish the tools I would use along the way – including instructions or setting it up on your boxes. If you like this subscribe to this URL and you can directly see posts only applicable to this topic.



Next > Finding the Problem
